A hobbyist has developed a new version of a voltmeter clock, focusing on better design and easier assembly. The project uses standard voltmeters, custom woodwork, and a microcontroller to display time via analog meters.
A hobbyist has unveiled a redesigned voltmeter clock that emphasizes aesthetic refinement and construction simplicity, using off-the-shelf voltmeters and custom woodworking. The project, shared on Hacker News, highlights a practical approach to building a unique, analog timepiece.
The new voltmeter clock features three generic 90° panel voltmeters, disassembled and customized with printed decals to display hours, minutes, and seconds. The design incorporates continuous motion for each hand, achieved through software-controlled pulse signals that drive the meters without requiring complex analog circuitry.
The enclosure is crafted from resawn maple lumber, with a CNC-milled front and back and a carefully bent side wall created by internal notches and moisture bending techniques. The assembly process involved precise fitting with templates, sanding, and finishing with nitrocellulose lacquer. The circuit is based on an AVR128DB28 microcontroller, powered by a wall wart, with simple pushbuttons for setting the time. The system uses pulse-width modulation of digital signals to control the meters’ positions, relying on their inertia and coil inductance to produce smooth movement.
Why It Matters
This project demonstrates how hobbyists can create functional and visually appealing analog clocks with readily available components and accessible woodworking techniques. It offers an alternative to digital displays, appealing to enthusiasts interested in electronics, craftsmanship, and unique design.
Such projects can inspire DIYers and educators by showing how to combine electronics and woodworking creatively, potentially leading to more personalized or artistic timepieces.
